SY103WAM19 Technical Data

Enabling Customer Innovation to Empower Tomorrow's Technology


SY103WAM19 Overview
SY103WAM19 is a 1.03inch diagonal, 2560(RGB) x 2560 dots active-matrix color OLED module, based on single-crystal siliconbackplate. This module integrates display driver and pixel driver circuit, and realizes small size, light weight, low powelconsumption and high resolution.

Screen Size:1.03 inch
Resolution:2560x2560
Brand:SeeYA
High Resolution OLED Panel
Refresh Rate:90Hz

Feature
-High contrast
-Wide color gamut
-Quick response
-Sunlight Readable
-Brightness:1000nits
-Operating Temp. :-20 ~ 70 °C
-Storage Temp. :-30 ~ 80 °C

Application
Head-mounted Displays, Viewfinders, Small Display,AR VR etc.

As one of the Pioneers within microdisplays products, Youritech have pushed energy efficiency to the edge, delivering high-performance Near-Eye Displays (NED) for a wide range of products, that include video glasses, head-mounted sports devices, camera viewfinders, medical applications, and many other professional devices worldwide.

Technical Data:
Part #：
SY103WAM19
Brand：
YOURITECH
Size：
1.03 inch"
Resolution：
2560x2560
Interface：
1.03 inch
Technology：
Si-OLED,OLED
Brightness：
1000nits
Operating Tem：
-20~70°C
Storage Tem：
-30~80°C
