M320QAN02.6 32 Inch 3840x2160 eDP (8 Lanes) IPS LCD Module

Enabling Customer Innovation to Empower Tomorrow's Technology

Home > Technologies > AUO > M320QAN02.6

M320QAN02.6 supports display 3840(RGB)×2160 (UHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 708.48(W)×398.52(H) mm, outline size of 721.88(W)×417.87(H)×40.61(D) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 4.76±0.23Kgs (Typ.). As a AHVA, Normally Black, Transmissive LCM product, M320QAN02.6 can provides 400 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 12 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 10-bit gray scale signal for each dot, thus presenting a palette of 1.07B colors, also with performance of color gamut 100% (Adobe). This product adopted Mini LED as it's backlight systerm which was placed as Direct light type and have a working life time of 30K hours, With LED Driver. M320QAN02.6 utilizes eDP (8 Lanes) as it's signal inputting systerm, which connected by 51 pins Connector with power supply voltage of 12.0V (Typ.). It's typical vertical frame rate (Fv) is 144Hz.

Technical Data:

Part #：

M320QAN02.6

Brand：

AUO

Size：

32.0 inch"

Resolution：

3840×2160

Interface：

eDP (8 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector

Technology：

Transmissive

Brightness：

400 cd/m² (Typ.)

Operating Tem：

0 ~ 50 °C

Storage Tem：

-20 ~ 60 °C
