HSD100NPN1-C00 10 Inch 1536x2048 Transflective Display Sunlight Readable LCD Display

Enabling Customer Innovation to Empower Tomorrow's Technology

Home > Technologies > HannStar > HSD100NPN1-C00

HSD100NPN1-C00 supports display 1536(RGB)×2048 with aspect ratio of 3:4 (W:H), whose pixels are arranged in RGB Vertical Stripe, it's pixel density is 255 PPI. As for mechanical detail, it features active area of 152.525(W)×203.366(H) mm, outline size of 156.53(W)×209.57(H)×0.8(D) mm, utilizing 0.40+0.40 mm mm plate. As a IPS, Normally Black, Transflective CELL product, HSD100NPN1-C00 can provides 1000:1 transimissive contrast ratio, 25:1 (Typ.) reflective contrast ratio, 65/65/65/65 (Typ.)(CR≥2) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 6 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + FRC gray scale signal for each dot, thus presenting a palette of 16.2M colors, also with performance of color gamut 7% (NTSC).

Technical Data:

Part #：

HSD100NPN1-C00

Brand：

HannStar

Size：

10 Inch"

Resolution：

1536x2048

Interface：

Technology：

Transmissive

Brightness：

Operating Tem：

-20~70°C

Storage Tem：

-30~83°C
