9.9 Inch 7680x4320 Monochrome LCD Display eDP IPS LCD Display For 3D Printer

Enabling Customer Innovation to Empower Tomorrow's Technology

Home > Technologies > YOURITECH > ET099FUH01-D

ET099FUH01-D is a 9.9-inch 8K monochrome IPS LCD display module with a 7680 × 4320 resolution, designed for 3D printer applications. It features a transmissive display mode with an eDP interface, an active area of 218.88 × 123.12 mm, and an outline dimension of 227.43 × 139.5 mm. The module supports viewing angles of 80° left/right/up/down and operates within a temperature range of 0–70 °C, with storage from -10–80 °C. This display does not include touch functionality.

Technical Data:

Part #：

ET099FUH01-D

Brand：

YOURITECH

Size：

9.9 inch"

Resolution：

7680x4320

Interface：

eDP

Technology：

Transmissive

Brightness：

Operating Tem：

0~70°C

Storage Tem：

-10~80°C

Name

Telephone

Touch screen customize: YesNo

Cover Glass customize: YesNo

Demo Kits: YesNo

Message

Integrated Display solutions

Touch screen, standard ready-made and customization

Supportrting capacitive touch screen (I2C interface, SPI interface, USB interface, UART interface)/ resistive touch screen / touch structure and function customization / optical bonding manufacturing.
Specific features:
High cost effective, automotive grade, industrial grade, medical grade solutions.
Durable and sturdy design for extreme environments.
Supports glove touch, multi touch, and stylus touch.
Featuring waterproofing, salt water resistance, low reflectivity, and 3D gesture touch control .

Driver board/adapter board, standard ready-made and design customization

DEMO board, HDMI board, other customized board, etc

Embbed Integrated Solution

UART display solution, HMI display solution, WINDOW display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
