9.5 Inch 1920x960 Stretched Bar Display IPS LVDS TFT LCD Display

Enabling Customer Innovation to Empower Tomorrow's Technology

Home > Technologies > YOURITECH > ET095BA01-YF

ET095BA01-YF is a 9.5-inch diagonal stretched bar TFT-LCD display product featuring a transmissive IPS panel. It supports a 1920 × 960 resolution, delivering a high-resolution wide-format display suitable for detailed graphical and information-rich applications, with pixels arranged in a standard RGB sub-pixel structure. The display features an active area of 216.806 (W) × 108.4 (H) mm and an outline dimension of 240 (W) × 130 (H) mm, enabling straightforward integration into compact system designs. ET095BA01-YF adopts an LVDS interface and provides a typical brightness of 400 cd/m², combined with wide viewing angles of 80° in all directions (L/R/U/D) to ensure consistent image quality. It is designed for reliable operation within an operating temperature range of –20 to 70°C and a storage temperature range of –30 to 80°C. This model does not support touch functionality and is well suited for industrial displays, embedded equipment, transportation systems, and information signage applications.

Technical Data:

Part #：

ET095BA01-YF

Brand：

YOURITECH

Size：

9.5 inch"

Resolution：

1920x960

Interface：

LVDS

Technology：

Transmissive

Brightness：

400 cd/m²

Operating Tem：

-20~70°C

Storage Tem：

-30~80°C

Name

Telephone

Touch screen customize: YesNo

Cover Glass customize: YesNo

Demo Kits: YesNo

Message

Integrated Display solutions

Touch screen, standard ready-made and customization

Supportrting capacitive touch screen (I2C interface, SPI interface, USB interface, UART interface)/ resistive touch screen / touch structure and function customization / optical bonding manufacturing.
Specific features:
High cost effective, automotive grade, industrial grade, medical grade solutions.
Durable and sturdy design for extreme environments.
Supports glove touch, multi touch, and stylus touch.
Featuring waterproofing, salt water resistance, low reflectivity, and 3D gesture touch control .

Driver board/adapter board, standard ready-made and design customization

DEMO board, HDMI board, other customized board, etc

Embbed Integrated Solution

UART display solution, HMI display solution, WINDOW display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
