2.1 Inch AMOLED Display MIPI 540×540 OLED Display With In-Cell Touch

Enabling Customer Innovation to Empower Tomorrow's Technology
Home > Technologies > YOURITECH > ET021CR01-HT
ET021CR01-HT is a 2.1 inch diagonal AMOLED display module with In-Cell Touch technology. ET021CR01-HT supports a 540×540 resolution with a 1:1 aspect ratio, delivering vivid colors, high contrast, and excellent image quality. It features a MIPI interface and adopts a transmissive display mode. The module has an active area of 53.14(W) × 53.14(H) mm and an outline dimension of 56.08(W) × 58.35(H) mm. ET021CR01-HT provides a typical brightness of 450 cd/m² and offers a wide viewing angle of 80/80/80/80 (L/R/U/D) for consistent visual performance from every direction. Integrated In-Cell Touch technology enables a thinner module structure with fast and accurate touch response. It operates reliably within a temperature range of -20°C to 70°C and supports storage temperatures from -30°C to 80°C, making it an ideal display solution for smart wearables, portable medical devices, industrial handheld equipment, and other compact embedded applications.
Technical Data:
Part #：
ET021CR01-HT
Brand：
YOURITECH
Size：
2.1 inch"
Resolution：
540x540
Interface：
MIPI
Technology：
Transmissive
Brightness：
450(Typ.)
Operating Tem：
-20~70°C
Storage Tem：
-30~80°C
Contact Us
Name
Email
Telephone
Touch screen customize:
Cover Glass customize:
Demo Kits:
Message
Integrated Display solutions
Touch screen, standard ready-made and customization
Supportrting capacitive touch screen (I2C interface, SPI interface, USB interface, UART interface)/ resistive touch screen / touch structure and function customization / optical bonding manufacturing.
Specific features:
High cost effective, automotive grade, industrial grade, medical grade solutions.
Durable and sturdy design for extreme environments.
Supports glove touch, multi touch, and stylus touch.
Featuring waterproofing, salt water resistance, low reflectivity, and 3D gesture touch control .
Driver board/adapter board, standard ready-made and design customization
DEMO board, HDMI board, other customized board, etc
Embbed Integrated Solution
UART display solution, HMI display solution, WINDOW display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
