COM27H2P41UTC 2.7 Inch TFT LCD Display 240x320 Transflective LCD Panel With 4-wire Resistive Touch

Enabling Customer Innovation to Empower Tomorrow's Technology
Home > Technologies > ORTUSTECH > COM27H2P92UTC
COM27H2P92UTC is a 2.7 inch diagonal a-Si TFT-LCD display screen product from Ortustech, with a built-in WLED backlight, without backlight driver, touchscreen 4-wire Resistive Touch.COM27H2P92UTC supports display 240(RGB)×320 (QVGA) with aspect ratio of 3:4 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 41.04(W)×54.72(H) mm, outline size of 47(W)×66(H)×5.64(D) mm, viewing area size of 43.74(W)×57.42(H) mm, net weight of 25.0g (Typ.). As a VA, Normally Black, Transflective LCM product, COM27H2P92UTC can provides 280 cd/m² display brightness 800:1 transimissive contrast ratio, 2:1 (Typ.) reflective contrast ratio, 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 100 (Max.)(Tr+Td) ms.
Technical Data:
Part #：
COM27H2P92UTC
Brand：
ORTUSTECH
Size：
2.7 inch"
Resolution：
240x320
Interface：
CPU/RGB
Technology：
Transflective
Brightness：
280(Typ.)
Operating Tem：
-20~70°C
Storage Tem：
-30~80°C
Contact Us
Name
Email
Telephone
Touch screen customize:
Cover Glass customize:
Demo Kits:
Message
Integrated Display solutions
Touch screen, standard ready-made and customization
Supportrting capacitive touch screen (I2C interface, SPI interface, USB interface, UART interface)/ resistive touch screen / touch structure and function customization / optical bonding manufacturing.
Specific features:
High cost effective, automotive grade, industrial grade, medical grade solutions.
Durable and sturdy design for extreme environments.
Supports glove touch, multi touch, and stylus touch.
Featuring waterproofing, salt water resistance, low reflectivity, and 3D gesture touch control .
Driver board/adapter board, standard ready-made and design customization
DEMO board, HDMI board, other customized board, etc
Embbed Integrated Solution
UART display solution, HMI display solution, WINDOW display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
